Application
ACSR Conductor is applied for large span overhead transmission and distribution lines or overhead ground wire of lines. Temperature for continuous use can be up to 75 ℃.
Structure
Aluminum-steel core consists of one or more concentrically stranded galvanized steel wires in the centre, and concentrically stranded aluminum wires in external layers, Small weight of aluminum and its good conductivity are combined with high resistance to elongation of steel.
|
Code |
Nominal Area |
Stranding |
Overall Diameter |
Weight |
Breakign Load S1A,S2A,S3A |
Electrical Resistance @20o |
Current Rating* |
|||
|
AL |
Steel |
Total |
AL |
Steel |
||||||
|
|
mm^2 |
mm^2 |
mm^2 |
No.×mm |
No.×mm |
mm |
Kg/Km |
KN |
Ω/Km |
A |
|
16 |
16 |
2.67 |
18.7 |
6/1.84 |
1/1.84 |
5.52 |
64.6 |
6.08/6.45/6.83 |
1.7934 |
85 |
|
25 |
25 |
4.17 |
29.2 |
6/2.30 |
1/2.30 |
6.9 |
100.9 |
9.13/9.71/10.25 |
1.1478 |
112 |
|
40 |
40 |
6.67 |
46.7 |
6/2.91 |
1/2.91 |
8.73 |
161.5 |
14.4/15.33/16.20 |
0.7174 |
150 |
|
63 |
63 |
10.5 |
73.5 |
6/3.66 |
1/3.66 |
10.98 |
254.4 |
21.63/22.37/24.15 |
0.4555 |
198 |
|
100 |
100 |
16.7 |
117 |
6/4.61 |
1/4.61 |
13.83 |
403.8 |
34.33/35.50/38.33 |
0.2869 |
263 |
|
125 |
125 |
6.94 |
132 |
18/2.97 |
1/2.97 |
14.85 |
397.9 |
29.17/30.14/31.04 |
0.2304 |
299 |
|
125 |
125 |
20.4 |
145 |
26/2.47 |
7/1.92 |
15.64 |
503.9 |
45.69/48.54/51.39 |
0.231 |
302 |
|
160 |
160 |
8.89 |
169 |
18/3.36 |
1/3.36 |
16.8 |
509.3 |
36.18/37.42/38.67 |
0.18 |
347 |
|
160 |
160 |
26.1 |
186 |
26/2.80 |
7/2.18 |
17.74 |
644.9 |
57.69/61.34/64.99 |
0.1805 |
351 |
|
200 |
200 |
11.1 |
211 |
18/3.76 |
1/3.76 |
18.8 |
636.7 |
44.22/45.00/46.89 |
0.144 |
398 |
|
200 |
200 |
32.6 |
233 |
26/3.13 |
7/2.43 |
19.81 |
806.2 |
70.13/74.69/78.93 |
0.1444 |
402 |
|
250 |
250 |
24.6 |
275 |
22/3.80 |
7/2.11 |
21.53 |
880.6 |
68.72/72.16/75.60 |
0.1154 |
458 |
|
250 |
250 |
40.7 |
291 |
26/3.50 |
7/2.72 |
22.16 |
1007.7 |
87.67/93.37/98.66 |
0.1155 |
461 |
|
315 |
315 |
21.8 |
337 |
45/2.99 |
7/1.99 |
23.91 |
1039.6 |
79.0382.08/85.13 |
0.0917 |
526 |
|
315 |
315 |
51.3 |
366 |
26/3.93 |
7/3.05 |
24.87 |
1269.7 |
106.83/114.02/121.20 |
0.0917 |
530 |
|
400 |
400 |
27.7 |
428 |
45/3.36 |
7/2.24 |
26.88 |
1320.1 |
98.36/102.23/106.10 |
0.0722 |
607 |
|
400 |
400 |
51.9 |
452 |
54/3.07 |
7/3.07 |
27.63 |
1510.3 |
123.04130.30/137.56 |
0.0723 |
610 |
|
450 |
450 |
31.1 |
481 |
45/3.57 |
7/2.38 |
28.56 |
1485.2 |
107.47111.82/115.87 |
0.0642 |
651 |
|
450 |
450 |
58.3 |
508 |
54/3.26 |
7/3.26 |
29.34 |
1699.1 |
138.42/146.58/154.75 |
0.0643 |
655 |
|
500 |
500 |
34.6 |
535 |
45/3.76 |
7/2.51 |
30.09 |
1650.2 |
119.41/124.25/128.74 |
0.0578 |
693 |
|
500 |
500 |
64.8 |
565 |
54/3.43 |
7/3.43 |
30.87 |
1887.9 |
153.8/162.87/171.94 |
0.0578 |
697 |
|
560 |
560 |
38.7 |
599 |
45/3.98 |
7/2.65 |
31.83 |
1848.2 |
133.74/139.16/144.19 |
0.0516 |
741 |
|
560 |
560 |
70.9 |
631 |
54/3.63 |
19/2.18 |
32.68 |
2103.4 |
172.59/182.52/192.45 |
0.0516 |
745 |
|
630 |
630 |
43.6 |
674 |
45/4.22 |
7/2.81 |
33.75 |
2079.2 |
150.45/156.55/162.21 |
0.0459 |
794 |
|
630 |
630 |
79.8 |
710 |
54/3.85 |
19/2.31 |
34.65 |
2366.3 |
191.77202.94/213.31 |
0.0459 |
798 |
|
710 |
710 |
49.1 |
759 |
45/4.48 |
7/2.99 |
35.85 |
2343.2 |
169.56/176.43/182.81 |
0.0407 |
851 |
|
710 |
710 |
89.9 |
800 |
54/4.09 |
19/2.45 |
36.79 |
2666.8 |
216.12/228.71/240.41 |
0.0407 |
856 |
|
800 |
800 |
34.6 |
835 |
72/3.76 |
7/2.51 |
37.61 |
2480.2 |
167.41/172.25/176.74 |
0.0361 |
910 |
|
800 |
800 |
66.7 |
867 |
84/3.48 |
7/3.48 |
38.28 |
2732.7 |
205.33/214.67/224.00 |
0.0362 |
912 |
|
800 |
800 |
101 |
901 |
54/4.34 |
19/2.61 |
39.09 |
3004.9 |
243.52/257.71/270.88 |
0.0362 |
916 |
|
900 |
900 |
38.9 |
939 |
72/3.99 |
7/2.66 |
39.9 |
2790.2 |
188.33/193.78/198.83 |
0.0321 |
972 |
|
900 |
900 |
75 |
975 |
84/3.69 |
7/3.69 |
40.59 |
3074.2 |
226.5/231.75/244.50 |
0.0322 |
974 |
|
1000 |
1000 |
43.2 |
1043 |
72/4.21 |
7/2.80 |
42.08 |
3100.3 |
209.26/215.31/220.93 |
0.0289 |
1031 |
|
1120 |
1120 |
47.3 |
1167 |
72/4.45 |
19/1.78 |
44.5 |
3464.9 |
234.53/241.15/247.77 |
0.0258 |
1096 |
|
1120 |
1120 |
91.2 |
1211 |
84/4.12 |
19/2.47 |
45.31 |
3811.5 |
283.17/295.94/307.79 |
0.0258 |
1100 |
|
1250 |
1250 |
102 |
1352 |
84/4.35 |
19/2.61 |
47.85 |
4253.9 |
316.04/330.29/343.52 |
0.0232 |
1165 |
|
1250 |
1250 |
52.8 |
1303 |
72/4.70 |
19/1.88 |
47 |
3867.1 |
261.75/269.14/276.53 |
0.0231 |
1163 |
